Logistic GPS Track Smart Electronic Lock 011
- 2G/3G/4G Smart Electronic Lock, bulit-in 10400maH battery, G-sensor and RFID reader, and monitor the container or asset’s location.
- Through the wireless technology, User can open the GPS lock remotely by SMS password or (android or IOS) app. If there is no cellular network,
- user can also open the lock by the authorized RFID key on spot.
product description
Logistic GPS Track Smart Electronic Lock
| Command content | *SPJLX*P:753869*C: # |
| Description
|
Query parameters |
| Terminal response | <SIM:2;IMEI:868703050814516;CREG:1;CSQ:30;IP:,URL:58.61.154.247,7018;APN:cmnet,,;ID:3050814516;ACC:0;LOC:0;R:30;WK:3;SLP:720;LOCK:2;VER:TL10_2022-08-18_16:37:35_V1.0> |
| Description
|
SIM:2; Current SIM card: SIM card 2
IMEI:868703050814516; Equipment IMEI CREG:1; CSQ:30; CSQ signal strength value IP:URL:58.61.154.247,7018; IP parameter APN: cmnet, APN Parameters ID:3050814516; Device id ACC:0; ACC status: 0 off, 1 on LOC:0; Positioning status: 0 not positioning, 1 positioning R:30; Lock report interval WK:3; working hours SLP:720; Sleep time LOCK:2; Lock cylinder status (0 unknown, 1 locked, 2 unlocked, 3 failed) VER:TL10__ 00_ 2022-08-18_ 16:37:35_ V1.0 Current software version number |
LED indicator:
: GSM-Red led : Cellular network connection Status
: GPS-Green led: GPS fix Status
: LVS-Yellow led: Low Battery Status
: CHG-Red led: Charging or Charging full Status
4 Product working Logic
Normally, if there is no any external wake up source, the device will go to sleep, and wake up according to RTC wake up interval (30 minutes as default value)
When swipe the RFID key, detected vibration, Back Cover Opened, Hard lock hook soft rope inserted and unplugging, RTC timing wake up, these Wake-up source will wake up this device, when device wake up, it will work about 10 minutes, during the 10 minutes, it reports position data according to Position Data Reporting Time interval (30 sec as default value).
7.5.1 Lock the device
When inserted the two ends of Hard lock hook soft rope inside device in place, the TL10 device will lock itself automatically.
Working Process: Buzzer ring once, Motor running, Buzzer ring twice.
‘Buzzer ring once’ indicates the device detects that both ends of the Hard lock hook soft rope are inserted into the proper position;
‘Buzzer ring twice’ Indicates that the device locked successfully.
Unlock by Password
Send below command via short message or Web platform
Working Process: When unlock successfully, Buzzer ring 3 second continuously, User can take out the Hard lock hook soft rope. After unlocking for 10 seconds, the Hard lock hook soft rope is not pulled out and the buzzer will continue to beep for 60 seconds; During the buzzer ringing, if the Hard lock hook soft rope is pulled out, the buzzer stops ringing; or after 60 seconds, the buzzer stops ringing and the device starts to lock automatically.
